FerroFinestra W75 TB Cor-Ten steel

Product Details-FerroFinestra W75 TB Cor-Ten steel

Product Introduction

FerroFinestra W75 TB Cor-Ten steel combines the superior performance of the W75 TB system with the charm of a natural material, ideal for both renovation works and new buildings. Maintaining the essential and clean design of the FerroFinestra family, W75 TB Cor-Ten steel allows for the housing of energy-efficient insulating glass. It enables the construction of any type of opening.

Main Features

  1. cold formed and sharp-edged 1,5 mm thick Cor-Ten steel profiles – high precision production lines
  1. continuously welded profile, high mechanical performance
  1. can be both internally and externally flush or overlapping, or externally flush and internally overlapping
  1. profile depth compatible with insulating glass up to 55 mm
  1. fiberglass-reinforced polyamide insulator
  2. wide choice of glazing beads, rectangular, triangular and double “L” shape
  1. EPDM co-extruded sealing gaskets
  2. wide choice of specific fittings, including both visible and conceived hinges
  1. side-hung, top-hung and bottom-hung windows, tilt and turn, pivoting windows, sliding and folding doors
  1. surface finish with the distinctive oxidation patina of Cor-Ten, properly stabilized

Optional
hardware

DSCF2415

The FerroFinestra W50 TB retains classic hot-rolled profiles with thermal break design.
DSCF2415

Surface
treatment style

Hot-rolled steel, cold-rolled steel, stainless steel,

weathered steel, corten steel, and architectural

bronze are the core materials of Rilang.

Cold-Rolled Steel

Cold-Rolled Steel
